Honeywell Gamewell-FCI E3 Series - 5: Cabinet a or AA, 3-Bay Installation Instructions

E3 Series Installation/Operation Manual — P/N 9000-0574:I 11/04/10 41
Cabinets Installation
2.5.5 Cabinet A or AA, 3-Bay Installation Instructions
The E3 Series
®
Cabinet A or Cabinet AA 3-Bay assembly typically includes the following:
• Backbox
– INI-VGC
• Outer Door
• Inner Door, 3-Bay:
• Hardware Kit
Figure 2.5.5.1 Cabinet A or AA, 3-Bay (Standard View)
– unit or Blank Plate – MIC
– ASM-16s – Blank Plates Optional
– NGA
–
