150 E3 Series Installation/Operation Manual — P/N 9000-0574:I 11/04/10
E3 Series System Connections Digital Alarm Communicator Transmitter (DACT-E3) Connections
3.10.6 DACT-E3 Wiring Connections
Table 3.10.6.1 lists the DACT-E3 wiring connections.
Designation Description Comments
TB1-1 COM A IN COM A from ILI-MB-E3/ILI95-MB-E3/ANX
TB1-2 COM B IN COM B from ILI-MB-E3/ILI95-MB-E3/ANX
TB1-3 COM A OUT COM A OUT to other devices
TB1-4 COM B OUT COM B OUT to other devices
TB1-5 +24 V IN + 24 VDC from PM-9/PM-9G TB4-1, TB4-3 or TB4-5
TB1-6 GND GND from PM-9/PM-9G TB4-2, TB4-4 or TB4-6
TB2-1 T1 Tip Line 1 Tip IN from street Non power-limited
TB2-2 T1 Ring Line 1 Ring IN from street Non power-limited
TB2-3 P1 Tip Line 1 Tip OUT to phone Non power-limited
TB2-4 P1 Ring Line 1 Ring OUT to phone Non power-limited
TB2-5 T2 Tip Line 2 Tip IN from street Non power-limited
TB2-6 T2 Ring Line 2 Ring IN from street Non power-limited
TB2-7 P2 Tip Line 2 Tip OUT to phone Non power-limited
TB2-8 P2 Ring Line 2 Ring OUT to phone Non power-limited
Table 3.10.6.1 DACT-E3 Wiring Connections
