52 E3 Series Installation/Operation Manual — P/N 9000-0574:I 11/04/10
Installation Cabinets
2.5.7 B-Slim Cabinet Installation
The B-Slim Cabinet Assembly typically houses the following:
• Backbox
– batteries
• Outer Door
– Door Insert
– LCD-E3 Display
• B-Slim Plate
• B-Slim Plate (Optional mounted on top of the ILI-MB-E3/ILI95-MB-E3)
• Hardware Kit
Figure 2.5.7.1 B-Slim Cabinet Installation
– ILI-MB-E3 – ILI95-MB-E3 – PM-9/PM-9G
– DACT-E3 – RPT-E3 – ANX
AC POWER
ON
POWER
FAULT
GROUND
FAULT
ALARM
SYSTEM
TROUBLE
 SYSTEM
SILENCED








MENU BACKSPACE/
EDIT
OK/
ENTER
< >




















