Honeywell Gamewell-FCI E3 Series - 3.8.9 PM-9 G Wiring Diagram

136 E3 Series Installation/Operation Manual — P/N 9000-0574:I 11/04/10
E3 Series System Connections PM-9/PM-9G Power Supply Connections
3.8.9 PM-9G Wiring Diagram
Figure 3.8.9.1 illustrates wiring diagram for the PM-9G sub-assembly.
Figure 3.8.9.1 PM-9G Wiring Diagram
JMP1
TB3
BATT+
BATT-
TB4
     
L2
J1
1
2
9
10
TB1

C12

L1
D6
T1
Q1
55 AH BATTERIES
MAXIMUM
(NON PWR-LIMITED)
BACKUP BATTERY (+) POS BACKUP BATTERY (-) NEG
EXTERNAL POWER OUTPUT 24VDC (+) EXTERNAL POWER OUTPUT GND (-) EXTERNAL POWER OUTPUT 24VDC (+) EXTERNAL POWER OUTPUT GND (-) EXTERNAL POWER OUTPUT 24VDC (+) EXTERNAL POWER OUTPUT GND (-) 24VDC @ 9 AMPS FROM ANY EXT. PWR OUTPUT 9 AMPS TOTAL FROM PM-9G (NON-PWR-LIMITED)






240VAC NEUTRAL (WHITE)
NOTE 4: DISABLE THE GROUND
FAULT DETECTION CIRCUIT WHEN
THE PM-9G IS CONNECTED BY A RIBBON CABLE TO AN ILI-MB-E3, ILI95-MB-E3 OR AN ANX.
GROUND (GREEN) 240VAC HOT (BLACK)
TO ILI95-MB-E3, ILI-MB-E3 OR ANX J1 CONNECTOR OR INI-VG J4 CONNECTOR
PIN1
   
+
+
6
7
1
12
NOTE 3: CONNECTION MUST BE TO A DEDICATED BRANCH CIRCUIT
AND MECHANICALLY PROTECTED.
ALL MEANS OF DISCONNECTING THIS CIRCUIT MUST BE CLEARLY MARKED “FIRE ALARM CONTROL” AND BE ACCESSIBLE TO AUTHORIZED PERSONNEL ONLY (NON PWR-LIMITED).
NOTE1: CB1 IS AN OPTIONAL FORM OF AC POWER PROTECTION.
D2 D4
D3
GREEN LED
BATTERY FAULT YELLOW LED
GROUND FAULT YELLOW LED
AC POWER
NOTE 5: CUT JMP2 (0 OHMS RESISTOR) FOR 240VAC APPLICATIONS.
JMP2
(SEE NOTE 5)
x
x
(SEE NOTE 1)
CB1
CB
x
x
