E3 Series Installation/Operation Manual — P/N 9000-0574:I 11/04/10 99
Intelligent Loop Interface-Main Board Connections E3 Series System Connections
3.2.1 Intelligent Loop Interface-Main Board (ILI-MB-E3) Wiring
Connections
Field wiring connections for the ILI-MB-E3 are shown in Table 3.2.1.1. All wiring is Power-
limited except the local energy City Box which is non power-limited.
Designation Description Comments
TB1-1, TB1-3 +24 V IN +24 VDC Input from PM-9/PM-9G TB4-1
TB1-2, TB1-4 GND Common negative from PM-9/PM-9G TB4-2
TB2-1 NAC1 B+ Notification Appliance Circuit 1 (See Note 6)
TB2-2 NAC1 B - Notification Appliance Circuit 1 (See Note 6)
TB2-3 NAC 1 A+ Notification Appliance Circuit 1 (See Note 6)
TB2-4 NAC 1 A- Notification Appliance Circuit 1 (See Note 6)
TB2-5 NAC2 B+ Notification Appliance Circuit 2 (See Note 6)
TB2-6 NAC2 B- Notification Appliance Circuit 2 (See Note 6)
TB2-7 NAC 2 A+ Notification Appliance Circuit 2 (See Note 6)
TB2-8 NAC 2 A- Notification Appliance Circuit 2 (See Note 6)
TB3-1 AUX RS485 A Output to LCD-E3, ASM-16, ANU-48, LCD-7100, DACT-E3 (See Note 3)
TB3-2 AUX RS485 B Output to LCD-E3, ASM-16, ANU-48, LCD-7100, DACT-E3 (See Note 3)
TB3-3 Earth Ground Connect to water pipe ground
TB3-4 Resettable B+ Auxiliary resettable 24 VDC power
TB3-5 GND Common negative
TB3-6 Non-resettable B+ Auxiliary non-resettable 24 VDC power
TB3-7 GND Common negative
TB3-8 Municipal Ckt + Output to Local Energy City Box or Remote Station or Releasing Solenoid -
Non Power-limited (See Note 7)
TB3-9 Municipal Ckt - Output to Local Energy City Box or Remote Station or Releasing Solenoid –
Non Power-limited (See Note 7)
TB4-1 SLC 2 A- SLC 2 Style 6 / 7 Return (See Note 5)
TB4-2 SLC 2 A+ SLC 2 Style 6 / 7 Return (See Note 5)
TB4-3 SLC 2 B- SLC 2 Style 4 / 6 / 7 Out (See Note 5)
TB4-4 SLC 2 B+ SLC 2 Style 4 /6 / 7 Out (See Note 5)
TB4-5 SLC 1 A- SLC 1 Style 6 / 7 Return (See Note 5)
TB4-6 SLC 1 A+ SLC 1 Style 6 / 7 Return (See Note 5)
TB4-7 SLC 1 B- SLC 1 Style 4 / 6 / 7 Out (See Note 5)
TB4-8 SLC 1 B+ SLC 1 Style 4 / 6/ 7 Out (See Note 5)
TB5-1 Alarm DC NC Alarm relay contact, N/C
TB5-2 Alarm DC NO Alarm relay contact, N/O
TB5-3 Alarm DC Common Alarm relay contact, Common
TB5-4 Supv DC NC Supervisory relay contact, N/C
TB5-5 Supv DC NO Supervisory relay contact, N/O
TB5-6 Supv DC Common Supervisory relay contact, Common
TB5-7 Trbl DC NC Trouble relay contact, N/C
TB5-8 Trbl DC NO Trouble relay contact, N/O
TB5-9 Trbl DC Common Trouble relay contact, Common
Table 3.2.1.1 ILI-MB-E3 Field Wiring Connections
