E3 Series Installation/Operation Manual — P/N 9000-0574:I 11/04/10 17
Specifications System Overview
1.5.3 Notification Appliance Circuits (ILI-MB-E3 or ILI95-MB-E3)
• Two (2), Class “A”, Style Z, or Class “B” Style Y circuits.
• Power-limited
• Supervised
• Non-coded
• Maximum alarm load - 2.0 amp per circuit
Refer to the Compatibility Addendum to Gamewell-FCI Manuals, P/N 9000-0427, Section 2 for a
list of UL Listed, compatible notification appliances.
1.5.4 Alarm Dry Contacts (ILI-MB-E3 or ILI95-MB-E3)
• Form “C”
• Rated 2 amp @ 30 VDC (resistive)
1.5.5 Trouble Dry Contacts (ILI-MB-E3 or ILI95-MB-E3)
• Form “C”
• Rated 2 amp @ 30 VDC (resistive)
1.5.6 Supervisory Dry Contacts (ILI-MB-E3 or ILI95-MB-E3)
• Form “C”
• Rated 2 amp @ 30 VDC (resistive)
1.5.7 Earth Ground Connection (ILI-MB-E3 or ILI95-MB-E3)
1.5.8 24 VDC Power, System (ILI-MB-E3 or ILI95-MB-E3)
• Unregulated FWR
• Resettable and non-resettable, 2.0 amp maximum per each circuit, 2.5 amp maximum
combined
• Unsupervised
• Power-limited
1.5.9 RS-232 Port
The RS-232 port consists of the Terminal Block TB6 which provides a standard serial port for the
connection to a Listed output device for a supplementary type service. Typical examples of such
devices include any UL Listed EDP device (remote printer or video terminal), any UL Listed
Signaling Device (such as the Keltron VS4095/5 printer), or any UL Listed Signal System Unit.
Ratings: 15 VDC (max.)
.05 amp (max.) current
115.2 K baud
8 bits, 1 stop bit, no parity
!
CAUTION: EARTH GROUND CONNECTION REQUIREMENT
TERMINAL TB3-3 MUST BE CONNECTED TO AN EARTH GROUND CONNECTION PER
ARTICLE 760 OF THE NATIONAL ELECTRIC CODE. FAILURE TO MAKE PROPER EARTH
GROUND CONNECTION TO A METALLIC COLD WATER PIPE OR DRIVEN GROUND ROD
TO THIS TERMINAL WILL RESULT IN THE LOSS OF LIGHTNING PROTECTION, REDUCE
THE TOLERANCE OF THE SYSTEM TO TRANSIENTS, AND WILL ADVERSELY AFFECT THE
OPERATION OF THE SYSTEM. PANEL NEUTRAL OR CONDUIT GROUND IS NOT
ACCEPTABLE, MINIMUM WIRE SIZE IS 14 AWG.
