E3 Series Installation/Operation Manual — P/N 9000-0574:I 11/04/10 121
Addressable Node Expander (ANX) Connections E3 Series System Connections
3.7.7.1 ANX-MR-UTP Wiring Connections
Table 3.7.7.1.1 lists the wiring connections for the ANX-MR-UTP.
Designation Description Comments
TB1-1 +24V +24 VDC Input from the PM-9/PM-9G TB4-1
TB1-2 GND Common negative from the PM-9/PM-9G TB4-2
TB1-3 +24V
TB1-4 GND
TB2-1 COM A IN Local Differential ARCNET
TB2-2 COM B IN Local Differential ARCNET
TB2-3 COM A OUT Local Differential ARCNET
TB2-4 COM B OUT Local Differential ARCNET
TB3-1 RS-232 GND To red lead on download cable P/N 75267
RS-232 Download
or Printer Port
TB3-2 RS-232 TxD To black lead on download cable P/N 75267
TB3-3 RS-232 SUPV Optional Printer Supervision
TB3-4 RS-232 RxD To green lead on download cable P/N 75267
TB4-1 ARCNET PORT 1A Secondary Broadband Network (See Note 1)
TB4-2 ARCNET PORT 1B Secondary Broadband Network (See Note 1)
TB4-3 ARCNET PORT 2A Secondary Broadband Network (See Note 1)
TB4-4 ARCNET PORT 2B Secondary Broadband Network (See Note 1)
W1, W2, W3 Factory Jumpers Factory Use Only or Right (Default OUT)
W4 ARCNET Termination OPEN = Normal Operation
SHORT = If the ANX is located at the end of the ARCNET bus.
W5 Network Ground Fault UP: = Supervise Secondary Network for GND FLTs
DOWN or OUT: = No Network GND FLT Supervision
SW1-1 Serial Communication ON = RS-232 115.2 kbits/sec OFF = defined by
CAMWorks™
SW1-2 thur SW1-8 Not Used
SW2-1 RING SELECT Ring/Node Assignment (See Table 3.7.7.1.2)
SW2-2 RING SELECT Ring/Node Assignment (See Table 3.7.7.1.2)
SW2-3 RING SELECT Ring/Node Assignment (See Table 3.7.7.1.2)
SW2-4 RING SELECT Ring/Node Assignment (See Table 3.7.7.1.2)
SW2-5 Not Used
J1 ETHERNET To FocalPoint or TCP/IP Network Port
Green LED-Communication link established (blinks with message
traffic)
Yellow LED-100 Mbps speed (Off = 10 Mbps)
J2 Local ARCNET Connects to J5 of the next ILI-E3, ILI95-E3 Series or ANX
J4 ARCNET Repeater Connector Connects to J10 of the RPT-E3
J5 Local ARCNET Connects to J2 from the previous ILI-E3, ILI95-E3 Series or
ANX
LED1 REC Network Reconfiguration
Primary
(Local Network)
LED2 MRC Network Reconfiguration originating from this node
LED3 DUP Node’s Network Address is duplicated at another node
LED4 TX Node is transmitting data to the network
LED5 RX Node is receiving data from the network
LED6 RST Node is resetting
LED7 DG General Network Fault
LED8 REC Network Reconfiguration
Secondary
Network
LED9 MRC Network Reconfiguration originating from this node
LED10 DUP Node’s Network Address is duplicated at another node
LED11 TX Node is transmitting data to the network
LED12 RX1 Node1 is receiving data from the network
LED13 RX2 Node2 is receiving data from the network
LED14 RST Node is resetting
LED15 DG General Network Fault
Note 1: The TB4-ANX UTP Network Connections use unshielded, twisted-pair 18 AWG min. 3,000 ft. (914.4m)
maximum between the following nodes:
• ANX TB4-1 (COM 1A) INI-VG TB1-3, RPT-E3 TB1-3
• ANX TB4-2 (COM 1B) INI-VG TB1-4, RPT-E3 TB1-4
• ANX TB4-3 (COM 2A) INI-VG TB1-1, RPT-E3 TB1-1
• ANX TB4-4 (COM 2B) INI-VG TB1-2, RPT-E3 TB1-2
Table 3.7.7.1.1 ANX-MR-UTP Wiring Connections
