144 E3 Series Installation/Operation Manual — P/N 9000-0574:I 11/04/10
E3 Series System Connections Digital Alarm Communicator Transmitter (DACT-E3) Connections
3.10 Digital Alarm Communicator Transmitter (DACT-E3)
Connections
The DACT-E3 digital communicator transmitter is an optional sub-assembly that features
numerous formats for the communication to a central station. It provides the following functions:
• Line seizure - takes control of the phone lines, disconnecting any premises phones using the
same lines
• Off/On-Hook - perform on and off-hook status to phone lines
• Listen for dial tone - 440 Hz tone typical in most networks
• Dialing the Central Station phone number - programmable
• Discern proper Central Station “ACK” and “Kiss-off” tone
• Transmit data to the Central Station
• Verify that data has been accepted by the Central Station
• Hang-up and release phone lines
• Communicate in a variety of formats
• Remote via the RS-485 serial interface
3.10.1 Central Station Reporting
UL Listed receivers compatible with the E3 Series
®
are listed in Table 3.10.1.1.
Manufacturer Receiver Model Formats
Silent Knight Model 9000. SIA-8
SIA-20
SK4/2
3/1 14
3/1 23
Silent Knight Model 9800/9500 SIA-8
SIA-20
SK4/2
3/1 14
3/1 23
Contact ID
Ademco Model 685 3/1 14
3/1 23
Sur-Guard
(Version. 1.64 or higher)
SG-MLR2-DG SIA-8
SIA-20
SK4/2
3/1 14
3/1 23
Contact ID
Osborne Hoffman Quickalert SIA-8
SIA-20
If you are using the Model 9000 and the message, “HELP,” appears on the printer after attempting
to download, the 9000 software must be upgraded.
The Model 9000 must have the Model 9307 software package, Revision 900501 or later, to print the
PROGRAMMING PASS and PROGRAMMING FAIL messages.
Table 3.10.1.1 UL Listed Receivers Compatible with the E3 Series
