E3 Series Installation/Operation Manual — P/N 9000-0574:I 11/04/10 149
Digital Alarm Communicator Transmitter (DACT-E3) Connections E3 Series System Connections
3.10.5.1 Reporting Codes for Non-SLC-Device Events
For events that do not originate on SLC devices, the DACT-E3 reports extended codes in the range
900-999. These codes are not user-configurable. Figure 3.10.5.1.1 lists the extended codes.
Code Event Comment
000 Phone Line Test Automatic DACT test OK.
001 - 899 SLC Device Codes User-defined in device configuration
900 Reserved
901 SLC 1 Loop Break, Short, or Disconnect
902 SLC 2 Loop Break, Short, or Disconnect
903 NAC 1 Fault, Short, or Disconnect
904 NAC 2 Fault, Short, or Disconnect
905 Municipal Circuit Master Box Trouble
906 Aux Power Fault Resettable or Non-Resettable B+ Fault
907 Municipal Circuit Supervision
908 Positive Ground Fault
909 Negative Ground Fault
910 RS-232 Supervision Fault
911 Annunciator Fault
912 PM-9/PM-9G Supervision
Fault
913 Battery Low
914 Battery Fault
915 AC Fault
916 DC Fault
917 Reserved
918 Battery Charger Fault
919 - 924 Reserved
925 DACT Account 1 Fault
926 DACT Missing
927 DACT Report Timeout
928 DACT Account 2 Fault
929 DACT Line 1 Fault
930 DACT Line 2 Fault
931 INI Communication Fault
932 INI Node Number Fault Issued if node address DIP switches do not match the node number
in the node’s configuration.
933 Net Port 1
934 Net Port 2
935 - 950 Reserved
951 - 981 Cross Zone 1 - 31 Cross Zone 31 (981) is used to report Group Cross Zone Events.
982 Node Missing Faults Node not reported
983 Node Extra Faults Node not reported, reports only when Extra Node enabled
984 LCD Display Faults Address not reported
985 ASM/ANU Faults Address not reported
986 External Faults e.g. INI-VG troubles that have no ILI equivalent
987 - 999 Reserved
991 Test with Exception Automatic DACT test OK, but Trouble condition present in the system.
992 - 999 Reserved
Table 3.10.5.1.1 Non-SLC Device Events Reporting Codes
