Honeywell Gamewell-FCI E3 Series - Cabinet B, Outer Door Installation

E3 Series Installation/Operation Manual — P/N 9000-0574:I 11/04/10 47
Cabinets Installation
2.5.6.3 Cabinet B, Outer Door Installation
1. Mount the outer door on the backbox.
2. Secure with four (4), #6 nuts in the four-hole mounting pattern on the left side of the backbox
as shown in Locations 1, 2, 3, and 4 of the figure below.
Figure 2.5.6.3.1 Cabinet B, Outer Door Installation
CABINET B,
OUTER DOOR
1
2
3
4
CABINET B,
BACKBOX
N
U
T
,
#
6
,
H
E
X
4
P
L
A
C
E
S
