E3 Series Installation/Operation Manual — P/N 9000-0574:I 11/04/10 173
Audible/Visual Condition Indications Programming/Operation Instructions
4.2 Audible/Visual Condition Indications
Table 4.2.1 lists the Audible/Visual Condition Indicators.
Condition Audible/Visual Status Indication
Alarm Alarm situations are indicated by a one-half second on and one-
half second off pattern from the system sounder and the
illumination of the red alarm LED.
Supervisory Supervisory events are indicated by a continuous tone from the
system piezo sounder and the illumination of the supervisory LED.
Trouble Trouble conditions are indicated by a continuous tone from the
system piezo sounder and the illumination of the yellow trouble
LED.
Acknowledged Acknowledgement of any of these conditions will silence the
system sounder leaving the appropriate LEDs illuminated.
Trouble Reminder The system defaults to automatic trouble resound so an
acknowledged trouble won't be overlooked. The time interval and
disabling of this function can be programmed in the configuration
tool (CAMWorks™).
Table 4.2.1 Audible/Visual Condition Indicators
