Cabinets Installation
2.5.7.3 B-Slim Cabinet Backbox Installation
To mount the B-Slim Cabinet outer door to the backbox, secure with four (4), #6 Hex Kep nuts in
the four-hole mounting pattern on the left side of the backbox. See Locations 1, 2, 3, and 4 of
Figure 2.5.7.3.1.
Figure 2.5.7.3.1 B-Slim Cabinet Outer Door Installation
B-SLIM CABINET
BACKBOX
1
2
3
4
