E3 Series Installation/Operation Manual — P/N 9000-0574:I 11/04/10 139
ASM-16 Addressable Switch Connections E3 Series System Connections
3.9.3 ASM-16 Wiring Connections
For the ASM-16, ANU-48, INI-VG Series, ILI-MB-E3/ILI95-MB-E3, LCD-E3 or remote
enclosure installations, use the wiring connections in Table 3.9.3.1, and refer to Notes A-F in
Figure 3.9.4.1 for the ribbon cable and hardwire locations.
ASM-16 or ANU-48 to ASM-16 or ANU-48 Wiring
Designation Description Designation
From ASM-16 or ANU-48 Ribbon Cable To ASM-16 or ANU-48
J1 Ribbon Cable Connect To:
J1 - LCD-E3
J1,J2 - ANU-48
J3 - INI-VGC, INI-VGX, INI-VGE
J1,J2,J3 - ASM-16
J2 Ribbon Cable Connect To:
J1 - LCD-E3
J1,J2 - ANU-48
J3 - INI-VGC, INI-VGX, INI-VGE
J1,J2,J3 - ASM-16
J3 Ribbon Cable Connect To:
J1 - LCD-E3
J1,J2 - ANU-48
J3 - INI-VGC, INI-VGX, INI-VGE
J1,J2,J3 - ASM-16
J4 Emulator Factory Use Only
J5 Factory use only
JMP1 Termination Install Jumper only if the last device is on
RS-485 bus.
Note: See Note A in Figure 3.9.4.1 for the ribbon cable connection.
ASM-16 or ANU-48 to ASM-16 or ANU-48 Wiring
From ASM-16 or ANU-48 RS-485 COM A from previous device/to next
device.
Connect To:
TB1-1 COMM A Single Discrete Wire TB3-1 I
LI-MB-E3/ILI95-MB-E3
TB6-3
INI-VGC, INI-VGX, INI-VGE
TB1-3
DACT-E3
TB1-1 ASM-16, ANU-48
TB1-5 LCD-E3
TB1-1
LCD-7100
TB1-2 COMM B Single Discrete Wire RS-485 COM B from previous device/to next
device.
Connect To:
TB3-2
ILI-MB-E3/ILI95-MB-E3
TB6-2
INI-VGC, INI-VGX, INI-VGE
TB1-4
DACT-E3
TB1-2
ASM-16, ANU-48
TB1-6 LCD-E3
ASM-16 or ANU-48 to ASM-16 or ANU-48 Wiring
Table 3.9.3.1 ASM-16 or ANU-48 Wiring Connections
