156 E3 Series Installation/Operation Manual — P/N 9000-0574:I 11/04/10
E3 Series System Connections Repeater (RPT-E3) Connections
3.11.5 Repeater-E3 Wiring Connections (Continued)
Table 3.11.5.2 lists the Transmitter Output Power Jumper Settings for the RPT-E3.
Port 1 Port 2 Transmit
Power
J4 J5 J6 J7 J8 J9
OPEN OPEN OPEN OPEN OPEN OPEN 12.5%
SHORT OPEN OPEN SHORT OPEN OPEN 25.0%
OPEN SHORT OPEN OPEN SHORT OPEN 37.5%
SHORT SHORT OPEN SHORT SHORT OPEN 50.0%
OPEN OPEN SHORT OPEN OPEN SHORT 67.5%
SHORT OPEN SHORT SHORT OPEN SHORT 75.0%
OPEN SHORT SHORT OPEN SHORT SHORT 87.5%
SHORT SHORT SHORT SHORT SHORT SHORT 100.0%
Table 3.11.5.2 Transmitter Output Power Jumper Settings
