E3 Series Installation/Operation Manual — P/N 9000-0574:I 11/04/10 141
ASM-16 Addressable Switch Connections E3 Series System Connections
3.9.4 ASM-16 or ANU-48 Wiring Connections
Figure 3.9.4.1 illustrates the ASM-16 and ANU-48 wiring connections.
Figure 3.9.4.1 ASM-16 and ANU-48 Wiring Connections
TB 1
REMOTE
TB 1
REMOTE
TB 1
REMOTE
TB 1
REMOTE
TB 1
REMOTE
TB 1
REMOTE
A
A
A
A
A
A
B
B
D
E
C
F
A A
AA
NOTE A:
ASM-16 or ANU-48 to ASM-16 or ANU-48 wiring
ASM-16/ANU-48 to ASM-16/ANU-48
RS-485 Connection
NOTE C and F:
From local INI-VG or LCD-E3 J1
(RS-485 Local)
NOTE B, D and E:
HARDWARE RS-485 Port
(to/from module in
Different INCC cabinet)
From ILI-MB-E3/IL95-MB-E3
TB3-1, TB3-2, TB1-3 and TB1-4
RS-485 RIBBON CABLE
Connector (to/from module)
In same INCC Cabinet)
NOTE B:
To next ASM-16 or ANU-48
TB1 remote in next INCC
cabinet
NOTE A:
ASM-16 or ANU-48 to
ASM-16 or ANU-48 wiring
ASM-16/ANU-48 to ASM-16/
ANU-48 RS-485 connection
NOTE A:
ASM-16 or ANU-48 to
ASM-16 or ANU-48 wiring
ASM-16/ANU-48 to
ASM-16/ANU-48 RS-485
connection
To Next Page
