E3 Series Installation/Operation Manual — P/N 9000-0574:I 11/04/10 49
Cabinets Installation
Figure 2.5.6.4.2 Cabinet B, Backbox Sub-Assembly (Exploded View)
CABINET B,
BACKBOX
ILI-MB-E3/
ILI95-MB-E3
DACT-E3
PM-9/PM-9G RPT-E3
(NOTE: PCB
ORIENTATION)
B
A
T
T
E
R
I
E
S
ILI-MB-E3/ILI95-MB-E3,
8-HOLE MOUNTING
PATTERN
PM-9/PM-9G,
6-HOLE MOUNTING
PATTERN
STANDOFF,
3/16", #4-40 x 1.0"
8 PLACES PER
ILI-MB-E3/ILI95-MB-E3 PCB
SCREW,
#4-40 X 3/8"
4 PLACES PER
DACT-E3 PCB
SCREW,
#4-40 X 3/8"
6 PLACES PER
PM-9/PM-9G PCB
SCREW,
#4-40 X 3/8"
4 PLACES PER
RPT-E3 PCB
(NOTE: PCB
ORIENTATION)
(NOTE: PCB
ORIENTATION)
(NOTE: PCB
ORIENTATION)
1
3
1
3
3
2
2
2












































NOTE: THE ANX CAN
MOUNT ON TOP OF THE
ILI-MB-E3/ILI95-MB-E3
(IN PLACE OF THE
DACT-E3/RPT-E3).
2
2
3
3
