CARB Carbon Potential Function Block
Revision 11 HC900 Hybrid Control Designer Function Block Reference Guide 113
2/07
Table 35 CARB Alarms tab configuration parameters
Properties Group Parameter Index # Parameter Description Value or Selection
Alarm 1 Setpoint 1
23 Alarm 1 Setpoint 1 Value - this
is the value at which you want
the alarm type chosen below to
activate
–99999 to 99999 in
Engineering Units
Type
N/A Alarm 1 Setpoint 1 Type -
select what you want Alarm 1
Setpoint 1 to represent.
Selections:
NO ALARM
PV_HIGH
PV_LOW
DEV_HIGH
DEV_LOW
SP_HIGH
SP_LOW
OUT_HIGH
OUT_LOW
Setpoint 2
24 Alarm 1 Setpoint 2 Value Same as Alarm 1
Setpoint 1
Type
N/A Alarm 1 Setpoint 2 Type Same as Alarm 1
Setpoint 1
Alarm 2 Setpoint 1
25 Alarm 2 Setpoint 1 Value Same as Alarm 1
Setpoint 1
Type
N/A Alarm 2 Setpoint 1 Type Same as Alarm 1
Setpoint 1
Setpoint 2
26 Alarm 2 Setpoint 2 Value Same as Alarm 1
Setpoint 1
Type
N/A Alarm 2 Setpoint 2 Type Same as Alarm 1
Setpoint 1
Alarm Hysteresis Hysteresis
31 Alarm Hysteresis in % 0 % to 5 %
