Function Blocks
Revision 11 HC900 Hybrid Control Designer Function Block Reference Guide 41
2/07
Properties Group Parameter Index # Parameter Description Value or Selection
QH Multiplier Units Type (see
“UNITS” on
Ultrasonic tab) =
US Metric
MBTU/hr MJ/ hr
MBTU/
day
MJ/ day
Provides a time period
other than “per hour” or
“per day”
Enter Value.
For example, if “per minute” is
desired, set the unit to “per
hour” and the multiplier to 1/60.
Default = 1.0.
Example
Figure 8 AGA9UM function block example
