Revision 11 HC900 Hybrid Control Designer Function Block Reference Guide 1
2/07
Introduction
Overview
Purpose of this section
This Reference Guide presents detailed reference data for each function block. The reference data is
organized in alphabetical order by the Function Block type identification label.
There is a list of Function Blocks grouped in categories as they appear on the Hybrid Control Designer.
The presented data covers each control blocks
• function,
• inputs/outputs,
• point name,
• configuration parameters
• index numbers (used for reading [RCON] and writing [WCON] block parameter constants)
ATTENTION
Select the index number of the required parameter from the specific function block reference
data and enter it in the appropriate field in the “Read Constant Properties” (RCON) or “Write
Constant Properties” (WCON) dialog box.
• technical reference
• examples
Of course, data varies based on what is pertinent for each function block since they do not all have a point
name or configuration parameters and do not all require technical reference information.
Reader assumptions
It is assumed that you are familiar with the operation of the HC900 Hybrid Control Designer and its help or
its manual, HC900 Hybrid Control Designer User's Guide (51-52-25-110).
Accessing function block properties
Double click on the function block to access the function block properties dialog box.
