Function Blocks
LDLG Lead/Lag Function Block
Revision 11 HC900 Hybrid Control Designer Function Block Reference Guide 181
2/07
Example
HFigure 44 shows a Function Block Diagram using an LDLG function block to modify the PV signal for the
remote setpoint input of the PID control loop.
X
OUT
1
OUT2
Input
Lead only
Lag only
Figure 44 LDLG function block example
