Page #171 background image
Function Blocks
FGEN Function Generator Function Block
Revision 11 HC900 Hybrid Control Designer Function Block Reference Guide 157
2/07
Properties Group Parameter Index # Parameter Description Value or Selection
X10
9 X-value at Input Breakpoint 10 –99999 to 999999
X11
10 X-value at Input Breakpoint 11 –99999 to 999999
Y1
11 Y-value at Output Breakpoint 1 –99999 to 999999
Y2
12 Y-value at Output Breakpoint 2 –99999 to 999999
Y3
13 Y-value at Output Breakpoint 3 –99999 to 999999
Y4
14 Y-value at Output Breakpoint 4 –99999 to 999999
Y5
15 Y-value at Output Breakpoint 5 –99999 to 999999
Y6
16 Y-value at Output Breakpoint 6 –99999 to 999999
Y7
17 Y-value at Output Breakpoint 7 –99999 to 999999
Y8
18 Y-value at Output Breakpoint 8 –99999 to 999999
Y9
19 Y-value at Output Breakpoint 9 –99999 to 999999
Y10
20 Y-value at Output Breakpoint 10 –99999 to 999999
Y11
21 Y-value at Output Breakpoint 11 –99999 to 999999
Clear All Button Click on button to clear all breakpoint values.
