Function Blocks
Function block listings
Revision 11 HC900 Hybrid Control Designer Function Block Reference Guide 7
2/07
Function Block Type Identification Label See Page
MSF (Mass Flow)
H216
MUL (Multiplication - 2 Inputs)
H219
4MUL (Multiplication - 4 Inputs)
H221
NEG (Negate)
H223
NOT (Not Boolean Logic)
H224
ONDT (On Delay Timer)
H225
OFDT (Off Delay Timer)
H228
ON/OFF (On/Off Control)
H231
2OR (OR - 2 Inputs)
H243
4OR (OR - 4 Inputs)
H245
8OR (OR - 8 Inputs)
H247
PB (Pushbutton)
H250
PDE (Peer Data Exchange)
H254
PDR (Peer Data Read)
H259
PDW (Peer Data Write)
H261
PI (Pulse Input)
H263
PID (Proportional, Integral, Derivative)
H269
POUT (Pulse Output)
H266
PPO (Position Proportional Motor Control)
H293
PTMR (Periodic Timer)
H297
QDT (Quadrature)
H300
RACK (I/O Rack Monitor)
H300
RAI (Analog Input RCJ)
H303
RAMP (Ramp)
H310
RCON (Read Configuration Parameter Data)
H300
RCP (Recipe Selector)
H318
RH (Relative Humidity)
H320
ROC (Rate of Change)
H322
RSTAT (Redundancy Status)
H325
RSW (Rotary Switch)
H326
RTC (Real Time Clock)
H328
RTMR (Resettable Timer)
H330
SCB (Scale and Bias)
H333
SEQ (Sequencer)
H335
SPEV (Setpoint Programmer Event Decoder)
H340
SPP (Setpoint Programmer)
H343
SPS (Setpoint Scheduler)
H353
SPSA (Setpoint Scheduler Auxiliary)
H360
SQRT (Square Root)
H362
STFL (Setpoint Scheduler State Flags)
H371
STG (Stage)
H364
STRIG (Selectable trigger)
H372
STSW (Setpoint Scheduler Switch)
H374
SUB (Subtraction - 2 Inputs)
H375
4SUB (Subtraction - 4 Inputs)
H376
SW (Analog Switch)
H378
SYNC (Synchronize)
H380
