Function Blocks
SPS Setpoint Scheduler Function Block
354 HC900 Hybrid Control Designer Function Block Reference Guide Revision 11
2/07
Inputs
ENABL=
Level input to enable the block. Only checked in ready state.
Input is ignored if not connected.
NPGM
= Program Number (when SET is ON). See ATTENTION below.
NSEG = Starting Segment Number (when SET is ON). See ATTENTION below.
^SET = Pulse Input to load NPGM and SEG numbers. See ATTENTION below.
PV1 = 1
st
Process Variable
PV2 = 2
nd
Process Variable
PV3 = 3
rd
Process Variable
PV4 = 4
th
Process Variable
PV5 = 5
th
Process Variable
PV6 = 6
th
Process Variable
PV7 = 7
th
Process Variable
PV8 = 8
th
Process Variable
STRQ = for connection to the STQR output of the STSW function block. (See HFigure 101.) The STSW
block encodes discrete inputs to a form that will convey change mode requests from the STSW block:
0.0 No Change
1.0 Jog State
2.0 Guaranteed Hold State
4.0 Reset State
8.0 Hold State
16.0 Run State
32.0 Advance state
ATTENTION
If either or both NPGM and NSEG are connected directly to analog variables, when that
analog variable changes (for example: via a recipe load), then the Setpoint Scheduler block
will immediately use the new value internally.
If NPGM or NSEG is connected to any other function type then their values are loaded into the
SP Scheduler only when ^SET goes through a positive transition.
Outputs
PGM
= Current Program Number
SEG = Current Segment number
STA = Program State (Reset, Run, Hold, Ghold, Stop).
SP1 = Setpoint #1 Output (EU)
SP2 = Setpoint #2 Output (EU)
SP3 = Setpoint #3 Output (EU)
SP4 = Setpoint #4 Output (EU)
SP5 = Setpoint #5 Output (EU)
SP6 = Setpoint #6 Output (EU)
SP7 = Setpoint #7 Output (EU)
SP8 = Setpoint #8 Output (EU)
