Function Blocks
AI Function Block
Revision 11 HC900 Hybrid Control Designer Function Block Reference Guide 47
2/07
Type Range Low Range High EU
Pt100 -300 1200 F
Pt100 -184 316 C
Pt100 -300 600 F
Pt500 -184 649 C
Pt500 -300 1200 F
Pt1000 -40 260 C
Pt1000 -40 500 F
JIS100 -200 500 C
JIS100 -328 932 F
JIS100 -200 260 C
JIS100 -328 500 F
Cu10 -20 250 C
Cu10 -4 482 F
YSI405 10 37.8
YSI405 50 100
Ohms 0 200
Ohms 0 500
Ohms 0 1000
Ohms 0 2000
Ohms 0 4000
mA 4 20
mA 0 20
mV 0 10
mV 0 50
mV 0 100
mV -10 10
mV -50 50
mV -100 100
mV -500 500
V 0 1
V 0 2
V 0 5
V 0 10
V 1 5
V -1 1
V -2 2
V -5 5
V -10 10
Carbon 0 1250 mV
Oxygen -30 510 mV
