CALCulate Subsystem

CALCulate[1|2]:LIMit:FCOunt?

HP E4418B/E4419B Programming Guide 3-13

CALCulate[1|2]:LIMit:FCOunt?

This query is used to return the total number of limit failures for the

speciﬁed window.

If the appropriate STATe commands are set to ON, each time a

measurement is initiated on the speciﬁed window and the measurement

result is outside the limits, the counter is incremented by one.

If the measured value is equal to a limit, this is a limit pass.

The counter is reset to zero by any of the following commands:

• *RST

• CALCulate[1|2]:LIMit:CLEar:IMMediate

• CALCulate[1|2]:LIMit:CLEar:AUTO ON

When CALCulate[1|2]:LIMit:CLEar:AUTO is set to ON, the counter is

set to zero each time a measurement:

• is measured using MEASure?

• is read using READ?

• is initiated using:

■ INITiate[:IMMediate] or,

■ INITiate:CONTinuous ON.

When CALCulate[1|2]:LIMit:CLEar:AUTO is set to ONCE, the counter

is set to zero the ﬁrst time a measurement:

• is measured using MEASure?

• is read using READ?

• is initiated using:

■ INITiate[:IMMediate] or,

■ INITiate:CONTinuous ON.

The maximum number of errors is 2

-1. If more than 2

-1 errors are

detected the counter returns to zero.
