MEASurement Instructions
CONFigure[1|2]?
2-6 HP E4418B/E4419B Programming Guide
CONFigure[1|2]?
This query returns the present configuration of the specified window.
Syntax
The string returned depends on the setting of the CALCulate:MATH and
CALCulate:RELative:STATe commands.
The configuration is returned as a quoted string in the following format:
"<function> <expected_value>,<resolution>,<source list>"
<expected_value> returns the expected value sent by the last
CONFigure command or +20 dBm by default. Note that when the display
is showing dual windows this value is meaningless.
The <resolution> returned is the same as the value returned by
DISPlay:WINDow:RESolution?. The format of the return is <NR1> in
the range 1 through 4.
1. HP E4419B only.
CALCulate:MATH
CALCulate:
RELative:
STATe
Function <source list>
(SENSe1) OFF :POW:AC (@1)
(SENSe2)
1
OFF :POW:AC (@2)
(SENSe1) ON :POW:AC:REL (@1)
(SENSe2)
1
ON :POW:AC:REL (@2)
(SENSe1 - SENSe2)
1
OFF :POW:AC:DIFF (@1),(@2)
(SENSe2 - SENSe1)
1
OFF :POW:AC:DIFF (@2),(@1)
(SENSe1 - SENSe2)
1
ON :POW:AC:DIFF:REL (@1),(@2)
(SENSe2 - SENSe1)
1
ON :POW:AC:DIFF:REL (@2),(@1)
(SENSe1 / SENSe2)
1
OFF :POW:AC:RAT (@1),(@2)
(SENSe2 / SENSe1)
1
OFF :POW:AC:RAT (@2),(@1)
(SENSe1 / SENSe2)
1
ON :POW:AC:RAT:REL (@1),(@2)
(SENSe2 / SENSe1)
1
ON :POW:AC:RAT:REL (@2),(@1)
CONF
1
2
?
