*SRE <NRf>
15-18 HP E4418B/E4419B Programming Guide
*SRE <NRf>
The *SRE <NRf> command sets the Service Request Enable register bits.
This register contains a mask value for the bits to be enabled in the Status
Byte Register. A 1 in the Enable Register enables the corresponding bit in
the Status Byte Register; a 0 disables the bit. The parameter value, when
rounded to an integer and expressed in base 2, represents the bits 0 to 5
and bit 7 of the Service Request Enable Register. Bit 6 is always 0.
Table 15-5 shows the contents of this register. Refer to the pullout at the
end of chapter 1 for further information.
Table 15-5: *SRE Mapping
Syntax
Parameters
Bit Weight Meaning
0 1 Not used
1 2 Not used
2 4 Device Dependent
3 8 QUEStionable Status Summary
4 16 Message Available
5 32 Event Status Bit
6 64 Not used
7 128 OPERation Status Summary
Type Description/Default
Range of
Values
NRf A value used to set the Service Request
Enable Register.
0 to 255
*SRE
NRf
?
Space
