SENSe Subsystem
[SENSe[1]]|SENSe2:CORRection:LOSS2[:INPut][:MAGNitude] <numeric_value>
HP E4418B/E4419B Programming Guide 9-33
[SENSe[1]]|SENSe2:CORRection:LOSS2[:INPut][:MAGNitude] <numeric_value>
This command is used to enter a channel offset value for the power meter
setup, for example cable loss. The power meter then corrects every
measurement by this factor to compensate for the loss.
Entering a value for LOSS2 using this command automatically turns the
[SENSe[1]]|SENSe2:CORRection:LOSS2:STATe command to ON.
Loss and gain correction are a coupled system. This means that a loss set
by [SENSe[1]]|SENSe2:CORRection:LOSS2 is represented in
[SENSe[1]]|SENSe2:CORRection:GAIN2? command.
LOSS2 is coupled to GAIN2 by the equation
when the default unit is linear, and
when the default is logarithmic.
Syntax
Parameters
Item Description/Default Range of Values
numeric_value A numeric value. The default
value, DEF, is 0.00 dB. The value
for MIN is -100 dB. The value for
MAX is +100 dB.
-100 to +100 dB
DEF
MIN
MAX
Gain
1
Loss
-------------=
Loss Gain–=
SENS
1
CORR
SENS2
:
:INP
:MAGN
Space
?
numeric_value
DEF
MIN
MAX
MIN
MAX
Space
:LOSS2
