HP E4418B Programming Guide

prog.book : ch5disp.fm 3 Mon Feb 15 09:24:37 1999
DISPlay Subsystem
DISPlay:CONTrast <numeric_value>
HP E4418B/E4419B Programming Guide 5-3
DISPlay:CONTrast <numeric_value>
This command is used to control the display contrast. A contrast of:
• 0, represents a minimum contrast.
• 1, represents a maximum contrast.
When the supply power is cycled off then on the contrast sets to the
factory default for that particular power meter.
Syntax
Parameters
Example
Reset Condition
On reset, the contrast is not affected.
Item Description/Default Range of Values
numeric_value A numeric value for the contrast level.
The default, DEF, is the factory default
and can vary between power meters.
The value for MIN is 0. The value for
MAX is 1.
0 to 1
DEF
MIN
MAX
DISP:CONT 0.75 This command sets the display
contrast to 0.75.
DISP
:CONT
Space
?
numeric_value
DEF
MIN
MAX
MIN
MAX
Space
