STATus Subsystem
STATus:OPERation:TRIGger[:SUMMary]
10-16 HP E4418B/E4419B Programming Guide
STATus:OPERation:TRIGger[:SUMMary]
The operation status trigger summary register set contains information
on the trigger status of the power meter.
The following bits in these registers are used by the power meter:
These bits are set when the power meter enters the “wait for trigger”
state. Refer to Figure 1-8, “Trigger System,” on page 1-63.
These bits are cleared when the power meter enters the “idle” state. Refer
to Figure 1-8, “Trigger System,” on page 1-63.
Syntax
Bit
Number
Decimal
Weight
Definition
0 - Not used
1 2 Channel A TRIGger Status
2 4 Channel B TRIGger Status (HP E4419B only)
3-15 - Not used
STAT
:OPER
:TRIG
:SUMM
