prog.book : ch3calc.fm 20 Mon Feb 15 09:24:37 1999
CALCulate Subsystem
CALCulate[1|2]:LIMit:UPPer[:DATA] <numeric_value>
3-20 HP E4418B/E4419B Programming Guide
Parameters
Example
Reset Condition
On reset, both channels are set to +90.00 dBm or +90 dB(DEF).
Query
CALCulate[1|2]:LIMit:UPPer[:DATA]? [MIN|MAX]
The query returns the current setting of the upper limit or the values
associated with MIN and MAX for the specified window.
Query Example
Item Description/Default Range of Values
numeric_value A numeric value. The default
value, DEF, is +90.00 dBm or
+90 dB. The value for MIN is
-150 dBm or -180 db. The value
for MAX is +230 dBm or +200 dB.
-150 to +230 dBm or
-180 to +200 dB
DEF
MIN
MAX
CALC2:LIM:UPP:DATA 5 This command enters an upper
limit for the lower window
depending on the windows units
as follows:
dBm = 5 dBm
W = 5 W
dB = 5 dB
% = 5 %
CALC2:LIM:UPP:DATA? This command queries the setting
of the upper limit for the lower
window.
