prog.book : ch13unit.fm 5 Mon Feb 15 09:24:37 1999
UNIT Subsystem
UNIT[1|2]:POWer <amplitude_unit>
HP
E4418B/E4419B Programming Guide
13-5
Query
UNIT[1|2]:POWer?
The query returns the current setting of the measurement units.
Query Example
UNIT2:POW?
This command queries whic
h
measurement units are being used
on the lower window
. In addition,
for the
HP
E4419B this command
also queries the default units for
any relevant SENSe2 command.
