HPE FlexNetwork MSR Series User Manual

225
Figure 238 The page for configuring a rule for an Ethernet frame header ACL
Table 114 Configuration items
Item Description
ACL
Select the Ethernet frame header IPv4 ACL for which you want to
configure rules.
You can use command line interface to create Ethernet frame header
IPv4 ACLs. For more information, see HPE FlexNetwork MSR Router
Series Comware 5 ACL and QoS Configuration Guide.
Rule ID
Select the
Rule ID
box, and enter a number for the rule.
If you do not specify the rule number, the system will assign one
automatically.
If the rule number you specify already exists, the following operations
modify the configuration of the rule.
Action
Select the action to be performed for IPv4 packets matching the rule:
• Permit—Allows matched packets to pass.
• Deny—Drops matched packets.
