HPE FlexNetwork MSR Series User Manual

226
Item Description
MAC
Address
Filter
Source MAC
Address
Select the
Source MAC Address
box, and enter a source MAC address
and wildcard.
Source Mask
Destination MAC
Address
Select the
Destination MAC Address
box, and enter a destination MAC
address and wildcard.
Destination Mask
COS(802.1p priority) Specify the 802.1p priority for the rule.
Type Filter
LSAP Type Select the
LSAP Type
box, and specify the DSAP and SSAP fields in the
LLC encapsulation by configuring the following items:
• LSAP Type—Frame encapsulation format.
• LSAP Mask—LSAP wildcard.
LSAP Mask
Protocol Type Select the
Protocol Type
box, and specify the link layer protocol type by
configuring the following items:
• Protocol Type—Frame type. It corresponds to the type-code field of
Ethernet_II and Ethernet_SNAP frames.
• Protocol Mask—Wildcard.
Protocol Mask
Time Range Select the time range during which the rule takes effect.
