Figure 439 Full customization

2. Configure the full customization settings as described in Table 188.

3. Click Apply.

Table 188 Configuration items

Item Description

Enable full customization Select this item to enable the full customization function.

Directory

Enter the directory where the customized page files are saved on the

SSL VPN gateway.

Page File Enter the name of the customized login page file.
