3. Bind call routes to the call number group:
Click Not Bound in the Call Routes Bound column on the Number Group tab page to access
the call route binding page.
The configuration of call route binding is similar to that of local number binding, and is not
shown.
A call route can be bound to multiple number groups in the same binding mode, that is, a call
route can either permit or deny the calls from bound number groups.
4. Bind IVR numbers to the call number group:
Click Not Bound in the IVR Numbers Bound column on the Number Group tab page to
access the IVR number binding page.
The configuration of IVR number binding is similar to that of local number binding. Therefore, it
is not included here.
Configuring a max-call-connection set
When you configure a max-call-connection set, first configure a max-call-connection set and specify
the maximum number of call connections in this set, and then bind the local numbers, call routes, or
IVR numbers to the max-call-connection set.
1. Add a max-call-connection set:
a. Select Voice Management > Dial Plan > Call Authority Control from the navigation tree.
b. Click the Max-Call-Connection Set tab.
The max-call-connection set configuration page appears.
Figure 624 Max-call-connection set page
c. Click Add to access the Max-Call-Connection Set Configuration page as shown in Figure
625.
Figure 625
Max-call-connection set configuration page
Table 235 Configuration items
Item Description
Connection Set ID Specify the ID of the max-call-connection set.
Max Number of Call
Connections in the Set
Specify the maximum number of call connections in the max-call-connection
set.
2. Bind local numbers to a max-call-connection set:
