353

Figure 735 E&M line configuration page

Table 274 Configuration items

Item Description

Basic Configurations

Description Description of the E&M line.

Cable Type

Select the E&M interface cable type: 4-wire or 2-wire.

By default, the cable type is 4-wire.

When you configure the cable type, make sure the cable type is

the same as that of the peer device. Otherwise, only unidirectional

voice service is available.

The configuration will be applied to all E&M interfaces of the card.
