444
Table 298 Configuration items
Item Description
Start Number
Specify the start number, and then a serial of consecutive numbers starting with the
start number will be bound to the selected voice subscriber lines. For example, if you
specify the start number as 3000 and select lines 3/0 and line 3/1, then line 3/0 is
bound to number 3000, and line 3/1 is bound to number 3001.
Register Mode
Set the register username and password in one of the following ways:
• Username and Password are the Same as Number.
• No Username and No Password.
• Username and Password are Specified Uniformly: If you select this option, you
need to set the username and password.
Register Username Username used for registration and authentication.
Register Password Password used for registration and authentication.
FXS Lines
• Selected FXS Lines.
• Available FXS Lines.
Select an FXS voice subscriber line in the
Available FXS Lines
box, click
<
to add
the line into the
Selected FXS Lines
box.
Select an FXS voice subscriber line in the
Selected FXS Lines
box, click
>
to
remove the line from the box.
Click
<<
to add all FXS voice subscriber lines in the
Available FXS Lines
box in to
the
Selected FXS Lines
box, and then click
>>
to remove all FXS voice subscriber
lines from the
Selected FXS Lines
box.
Fax and Modem
Select Voice Management > Advanced Configuration > Batch Configuration from the
navigation tree, and then click the Fax and Modem link in the Local Number area to access the
local number fax and modem configuration page, as shown in Figure 849.
Figure 849
Local numb
er fax and Modem configuration page
