3. Operation of CON Related Controllers
97
[Production information]
Touch [Production information] in Information screen.
Production information screen opens.
In this, shows manufacturing information such as the serial
number of the controller and actuators.
Actuator S/N, actuator model number and user note should
be displayed when both the controller and actuators are
applicable for the information management system and
Parameter No. 192 Actuator Identification System Use Flag
is set to 1: Valid.
For the Actuator S/N, actuator model number and user note,
the information saved in the encoder should be displayed.
Touch [User Note Editing] button, show the full keyboard,
and it is available to edit the memo.
The user note is available for editing up to 124 characters in
half size at the maximum. (Only half size alphabetical and
numerical characters and half size symbols are available for
input in TB-02.)
Refer to “Input Operation on Full Keyboard” in 3.10.2 for entering a text.
[Maintenance information]
Touch [Maintenance information] in Information screen.
Maintenance information screen opens.
Refer to [3.9.2 Maintenance Information Screen] for the
items to be shown and how to operate the buttons.
Last time lubricated and travel distance after lubrication
should be shown when both the controller and actuators
are applicable for the information management system and
Parameter No. 192 Actuator Identification System Use Flag
is set to 1: Valid.
