6. Operation of ELECYLINDER
368
6.16 Data Backup
Data is transferred between the Secure Digital memory card in the touch panel teaching pendant
and the controller.
(Note) Type of Stored Data
This includes the position data, parameters and alarm list.
It is not applicable to the backup data storable in the RC PC software.
(Note) Extensions of the Stored Data
• The file extensions of the data stored to the Secure Digital card are the same as
those dealt in RC PC software, and are compatible. For instance, the position data for
the PCON-C controllers is ptpc and the parameters are prpc.
[Refer to the details of the file extensions in the RC PC Software Instruction Manual]
• The alarm list can only have the backup. It cannot be restored. Data is in a CSV file.
(Note) Directories of the Stored Data
The folders to store the backup data of the controller and the folder to read the data
from when restoring the data to the controller are as listed below. The directories to
store the files cannot be changed. The files existing in other directories other than the
specified folders cannot be listed up in the file name list in the file select at the initial
setting or restore.
If the folder does not exist, it is automatically created.
• Position Data : \TB_CON\Position\File Name
• Parameter : \TB_CON\Parameter\File Name
• Alarm List : \TB_CON\Alarmlist\File Name
(Note) Files with Chinese names are not supported.
Caution: For a Secure Digital memory card, choose a SD/SDHC memory card with 1G to
32G. (Toshiba-made recommended) Also, use FAT32 Format for the file system.
