5. Operation of MEC Related Controllers
267
5.4 Initial Setting
When the power is turned on for the first time after the delivery of the controller, the initial
setting screen will appear.
Select [Yes], and the display will change to the initial setting screen where you can set the
operation pattern.
Select [No], and the factory set operation pattern, specifically the 2-point stopping
operation mode, will remain effective.
The display will switch to the position setting screen.
Factory settings
Operation pattern:
Stopping at 2 points
[Refer to 5.7, “Initial Setting.”]
[Refer to 5.8, “Position Setting.”]
No
Yes
To Next Page
