3. Operation of CON Related Controllers
31
3.3 Initial Screen
When the power is turned on, the IAI logo is displayed for approx. 1 second on the operation
display screen of the touch panel teaching pendant and then the version information is
displayed.
If multiple units are connected, the axis
selection screen a
ears.
Select an axis to be operated with TB-02.
[Refer to 3.4, "Changing Operating Axis."]
2.On TB-02D pendants, this screen is
displayed when the enable function
parameter of the controller is set to
“Disable.”
The Menu 1 screen appears.
Select either [Yes] (Activate
Enable Feature) or [No]
(Inactivate Enable Feature).
1. On TB-02 pendants, this screen is
displayed when the enable function
parameter of the controller is set to
“Enable.”
Select either [Yes] (Inactivate
Enable Feature) or [No] (Activate
Enable Feature).
When Multiple Units Connected
Enable Unmatched
When Multiple Units Connected
Enable Unmatched
To Next Page
