3. Operation of CON Related Controllers
35
3.6 Position Edit Guide
In the guide, explains how to input position data and how to make a trial run in two-way
communication style using the actual position data edit screen.
Operate in the order of [Introduction] → [Item select] → [Position input] → [Test run] → [End].
Touch [Position edit guide] icon.
After that, follow the instruction on the screen to operate.
Touch [←] button and the screen goes back to the previous window.
Some processes may be skipped depending on the actuator condition.
For the terms bracketed with “ ”, touch [Glossary] button at the bottom right of the screen and the
explanation can be confirmed.
Introduction
Item select
To Next Page
