1. Confirming the Specifications
1.1 Basic Specification
Item Specifications
Rated voltage
24V DC 10% (Supplied from controller)
Operating voltage range 21.6 to 26.4V DC
Power consumption 3.6W or less (150mA or less)
Insulation resistance Between GND and FG 500V DC 10MΩ
Display colors 65536 colors (16-bit colors)
Backlight method White LED backlight
Backlight life 15,000 hours
Touch panel screen 7 inch TFT color WVGA(800x480)
Touch detection method 4-wire resistive type
Touch panel life 1 million times
External memory
SD/SDHC memory card
interface installed (1G to 32G) (Toshiba-made recommended)
Cable length 5m (Standard), 10m (Maximum)
Wall mounting hook Hook available to use with M8 hex socket head cap screw
Touch pen (Accessory)
4.5×102mm
Language selection Japanese/English/Chinese
Touch sound ON/OFF Volume Settable in 3 steps, S, M, and L
Data save
Applicable to have data saved to and read from external Secure Digital
memory card (FAT32 Format) (Position data, parameter, alarm list)
Display adjustment Brightness adjustable for contrast and backlight
Time setting
Clock setting available with real time clock
(Backup held with CR2032 button battery)
Communication standard Based on RS485
Communication speed
9,600bps/14,400bps/19,200bps/28,800bps/38,400bps
/57,600bps/76,800bps/115,200bps/230,400bps
Duration from the power
being off to turned on
More than 2 seconds
Cooling method Natural air-cooling
Size
TB-02 : 155 mm (H) × 190 mm (W) × 25 [45.1] mm (D)
TB-02D : 155 mm (H) × 190 mm (W) × 55 [75.1] mm (D)
Stop switch included in [ ]
Weight
TB-02 : 470g approx. (Main Body) + 330g approx. (Cable 5m)
TB-02D : 600g approx. (Main body) + 330g approx. (Cable 5m)
SD memory card is a trademark of SD-3C, LLC and SDA.
