5.16 Monitor
The current position, speed, electrical current, system status and I/O statuses of the controller
are displayed.
Touch on the MEC menu screen.
Touch [Menu] to return to the MEC menu screen.
The operation
pattern is shown.
The servo status is shown.
The home return status is shown.
The axis position is shown.
The axis speed is shown.
The electrical current of the axis
is shown.
The I/O statuses of the
axis are shown.
The displayed signals
vary depending on the
operation pattern.
