3. Operation of CON Related Controllers
112
3.19 Data Backup
Data is transferred between the Secure Digital memory card in the touch panel teaching pendant
and the controller.
(Note) Type of Stored Data
This includes the position data, parameters and alarm list.
It is not applicable to the backup data storable in the RC PC software.
* For how to operate the press program data, refer to 3.26.4 Secure Digital Memory Card
(Note) Extensions of the Stored Data
• The file extensions of the data stored to the Secure Digital card are the same as those dealt
in RC PC software, and are compatible. For instance, the position data for the PCON-C
controllers is ptpc and the parameters are prpc.
[Refer to the details of the file extensions in the RC PC Software Instruction Manual]
• The alarm list can only have the backup. It cannot be restored. Data is in a CSV file.
(Note) Directories of the Stored Data
The folders to store the backup data of the controller and the folder to read the data from
when restoring the data to the controller are as listed below. The directories to store the files
cannot be changed. The files existing in other directories other than the specified folders
cannot be listed up in the file name list in the file select at the initial setting or restore.
If the folder does not exist, it is automatically created.
• Position Data
：
\TB_CON\Position\File Name
• Parameter
：
\TB_CON \Parameter\File Name
• Alarm List
：
\TB_CON \Alarmlist\File Name
(Note) Files with Chinese names are not supported.
Caution: For a Secure Digital memory card, choose a SD/SDHC memory card with 1G to
32G.
Toshiba-made recommended
Also, use FAT32 Format for the file s
stem.
