3. Operation of CON Related Controllers
153
Press Program
Monitor Screen Display List
Name Explanations
1 Servo The servo status is shown. ON is lit. OFF is unlit.
2 Homing
The home return status is shown.
Lit, if home return has completed.
3 Calibration
The status of loadcell calibration is shown.
Lit, if loadcell calibration has completed.
4 Cur. pos. The current position is shown.
5 Cur. vel. The current speed is shown.
6 Current load The current load is shown.
7 Analog output
It shows the analog current output from the MF I/F connector
on the controller in accordance with the current load.
8 Overload level Tthe overload level is shown.
9
Command current
rate
The command value of electrical current is shown as a
percentage of the rated current.
The current value will be shown if touching the command
current rate .
10 Feedbk. current ratio
It shows the rate of the feedback current to the rated value.
The current value will be shown if touching the feedback
current rate.
11
Command current
value
The command current value is shown.
The current rate will be shown if touching the command
current value.
12 Feedbk. Current Value
The feedback current is shown.
The current rate will be shown if touching the feedback current
value.
13 Alarm code
It shows the alarm codes of the controller.
It shows a blank if there is no alar occurred.
14 Program Alarm Code The program alarm code is shown.
15 PIO pattern It shows the PIO pattern numbers set to the controller.
16 Exe. Prg. No.
It shows the pressing program number currently being
executed.
17 IN
The press program home return status is shown. ON is lit.
OFF is unlit.
18 OUT The output status is shown. ON is lit. OFF is unlit.
19 Special Input port
It shows the status of such as the enable switch.
ON is lit. OFF is unlit.
