3. Operation of CON Related Controllers
155
Name Explanations
12
Feedbk. Current
Value
The feedback current is shown.
The current rate will be shown if touching the feedback current
value.
13 Alarm code
It shows the alarm codes of the controller.
It shows a blank if there is no alar occurred.
14 Program Alarm Code The program alarm code is shown.
15 Exe. Prg No.
It shows the pressing program number currently being
executed.
16 Comment
It shows the comment set in the pressing program number
currently being executed.
17 Mode
It shows the pressurizing operation mode set in the pressing
program number currently being executed.
18 Prg Home
The program home return status is shown. It turns on when
the movement operation to the program home position is
complete.
19 Stage
It shows the control stage of the pressing program number
currentl
y
bein
g
executed.
20 Pos. (Dist.) Judgment
It shows the result of the position (distance) judgment.
If the result is passed, it shows OK and NG if it resulted failed.
It shows blank before judgment is conducted.
21 Load Judgment
It shows the result of the load judgment.
If the result is passed, it shows OK and NG if it resulted failed.
It shows blank before judgment is conducted.
22 Total Judgment
It shows the result of the position (distance) judgment and the
load judgment.
It shows OK if both of the positon (distance) judgment and the
load judgment resulted passed.
It shows NG if both of the positon (distance) judgment and the
load judgment resulted failed.
It shows NG if the positon (distance) judgment resulted passed
but the load judgment failed, or the positon (distance)
judgment resulted failed while the load judgment passed.
It shows OK if the positon (distance) judgment resulted passed
but the load judgment unjudged, or the positon (distance)
judgment is unjudged while the load judgment resulted
passed.
It shows blank before judgment is conducted.
