3. Operation of CON Related Controllers
174
Press Program Jog Inching Screen Display List
Botton Name Explanations
1 Calibration
The loadcell calibration status is shown.
It turns on if calibration has been completed.
2 Cur. pos. The current position is shown.
3 Cru. vel. The current speed is shown.
4 Current load The current load is shown.
5 Analog Output
It shows the analog current output from the MF I/F connector
on the controller in accordance with the current load.
6 Overload level The overload level is shown.
7
Command Current
Rate
The command value of electrical current is shown as a
percentage of the rated current. The current value will be
shown if touchin
g
the command current rate.
8 Feedbk. Current Rate
It shows the rate of the feedback current to the rated value.
The current value will be shown if touching the feedback
current rate.
9
Command Current
Value
The command current is shown.
The current rate will be shown if touching the command current
value.
10 Feedbk. Current Value
The feedback current is shown.
The current rate will be shown if touching the feedback current
value.
