Botton Name Explanations
5) Search Stop
It performs the operation in the control stage [1. Approaching]
and [2. Searching] and stops an axis.
Touch [Prg Start] button while [Searching Stop] button is
selected, and an axis gets in the searching stop status, and gets
in the normal execution when it is not selected.
If it is executed with [1. Approaching] invalid, operation of only [2.
Searching] will be conducted.
If it is executed with [2. Searching] invalid, operation of only [1.
Approaching] will be conducted.
If it is executed with both [1. Approaching] and [2. Searching]
invalid, the axis operation will not be conducted.
6) Prg. Start The pressing program set in Start Prg No. should be executed.
7) Prg. Stop Touch [Stop], and the axis stops.
8) TrialRun w/Graph
It shows the pressing program run (graph) window.
[Refer to 3.26.3.3]
Press Program Operation Screen Display List
Botton Name Explanations
1
Figure of Control
Stage
It shows the status of the control stage being executed.
The arrow and letter for the control stage that is currently being
executed should be shown in red.
It shows the arrow and the letters in gray after the program has
been executed when operation in each control stage is
inactivated.
2 Axis Status Monitor main in common
3 Press Program Status Data monitor in common
Press Program Operation Screen Setting List
Botton Name Explanations
ⅰ
Start Prg. No.
The pressing program number to be executed first can be
indicated. When transited from the pressing program individual
edit window, the pressing program number can be carried over.
To Next Page
